• 36% Off RRP

Hoshizaki IM-240PE-28 Underbench Cube Ice Machine 180KG.

RRP $13,350.00 ex GST Our Price $8,554.00 ex GST Our Price $9,409.40 Inc GST
  • Cube Ice Machine - Self Contained
  • Exterior: Stainless steel AISI 441, Galvanized steel (Rear)
  • 195kg Ice production per day @ 10°C Air temp; 10°C Water
  • 180kg Ice production per day @ 21°C Air temp; 15°C Water
  • 160kg Ice production per day @ 32°C Air temp; 21°C Water
  • 110kg (storage bin control setting 80kg)
  • AC Supply Voltage: 1 PHASE 220-240V 50Hz/ 10 AMP Plug
  • Amperage: Running: 4.0A Rated Motor: 4.0A Starting: 27A
  • Refrigerant Charge: R290 / 147g
  • Operating Ambient: 1-40°C
  • Water Supply Temp.: 5-35°C
  • Water Supply Pressure: 0.07-0.8MPa (0.7 - 8bar)
  • Voltage Range: Rated Voltage ±6%
  • Electric Consumption: 870W
  • Electrical Circuit Breaker Protection: 5A
  • Heat Rejection (AT 32°C, WT 21°C): 2580W
  • Accessories Included: Installation kit, Legs, Scoop


Warranty: 3 years parts and labour

Daily Rental: $15.51 Inc GST
Product Enquiry

Product Description:

The Hoshizaki IM-240PE-28 is the new standard IM CUBE self-contained cuber from Hoshizaki, producing up to 195kg of Hoshizaki’s world-renowned hard and slowly melting 28mm cubes every 24 hours.

Set Yourself Up for Growth and Success

Features:

  • Sustainable & Efficient
  • The unit features a variable-speed magnetic DC pump motor and eco-friendly R290 refrigerant for reduced energy use. Stand-by mode, premium foamed insulation, and an improved water tank design help save both energy and water.
  • Durable & Hygienic Construction
  • A closed water circuit protects against contamination throughout ice production, while food-grade stainless steel (AISI 430) components minimise wear. An optional scoop holder kit supports hygienic ice handling.
  • Advanced Technology
  • Smart pump control adjust water flow during each ice-making phase to prevent chipped or cloudy cubes. The closed cell system ensures uniform, high-quality cube formation.
  • Smart & Long-Lasting Design
  • Automated cleaning with wash auto-restart, plus water circuit and condenser cleaning notification, simplify maintenance and extend the machine’s lifespan.
  • Compact & Space-Saving
  • Self-contained design delivers high output while optemising floor space, ideal for commercial kitchens with limited room.
  • Plug & Play Installation
  • User-friendly stand-by and wash buttons, adjustable dimple size controls, and removable water tank and DC pump make setup and maintenance quick and easy.

Production Capacity per 24hours:

  • Approx. 195kg @ 10°C Air temp; 10°C Water
  • Approx. 180kg @ 21°C Air temp; 15°C Water
  • Approx. 160kg @ 32°C Air temp; 21°C Water

Water Consumption per 24hours:

  • Approx. 0.67m³ @ 10°C Air temp; 10°C Water
  • Approx. 0.32m³ @ 21°C Air temp; 15°C Water
  • Approx. 0.29m³ @ 32°C Air temp; 21°C Water
More Information
SupplierHoshizaki
PowerPlease refer to Product Spec Sheet
Net Weight of Equipment (kg)108
Packaged Width (mm)805
Packaged Depth (mm)760
Package Height (mm)1684
Product Width (mm)704
Product Height (mm)1580
Product Depth (mm)665
